| Medium |
Compressed air, filtered to 40μm,
lubricated or non-lubricated
|
| Operation |
V44: Glandless spool valve, solenoid pilot or air pilot actuated
V45: Softseal spool valve, solenoid pilot or air pilot actuated
|
| Mounting |
Sub-base
|
| Media/Ambient temperature |
-15 … +50°C (+5 … 122°F)
V44/V45 solenoid and V45 air pilot models
-15 … +80°C (+5 … 176°F)
V44 air pilot models
Air supply must be dry enough to avoid ice formation at
temperatures below +2°C (+35°F).
|
| Materials |
Body: die-cast aluminium
Sub-bases: aluminium alloy
Spool and sleeve: hard anodized, Teflon coated, matched aluminium (V44); aluminium alloy spool with HNBR Seals (V45)
Plastic parts: POM
Static seals: NBR
End cover and screws: zinc plated
Springs: stainless steel
|
